Rotary Vaccum Evaporator
We are the leading manufacturer, supplier and trader of Rotary Vaccum Evaporator to our valuable clients.
Rotary Vacuum Evaporator With Thermostatic Control Bath
We introduce ourselves as an eminent manufacturer, trader and supplier of superior quality Rotary Vacuum Evaporator With Thermostatic Control Bath. Widely used in laboratories, offered evaporator is manufactured by our skilled professionals using modern technology and the best quality components in line with industry norms. Apart from this, provided evaporator is tested on diversified parameters in order to ensure its flawlessness. Our offered evaporator is widely appreciated by our clients for its variegated quality attributes.
Features
- Cone Adapter for condenser to Vacuum pump
- Vapour Path Tube B-24, B-29
- Gasket Seal for Vapour Tube (VITON)
Specifications
| Model | Description |
|---|---|
| R/150/01 | Condenser double coiled with S-35 cup. |
| R/150/03 | Gasket Seal for Vapour path Tube (VITON) |
| R/150/05 | Vapour Path Tube B-24, B-29 |
| R/150/06 | Feed Tube for condenser |
| R/150/07 | Evaporating flask R.B. 1 liter B-24 socket |
| R/150/08 | Receiving flask with S-35 cup (socket) joint capacity 1000 ml. |
| R/150/09 | Evaporating Flask Kjeldahl cap. 800 ml. B-24 |
| R/150/22 | Evaporating Flask Kjeldahl cap. 500 ml. B-24 |
| R/150/24 | Evaporating Flask Kjeldahl cap. 300 ml. B-24 |
| R/150/26 | Evaporating Flask Kjeldahl cap. 100 ml. B-24 |
| R/150/11 | Tension Spring to hold condenser. |
| R/150/13 | Wire Clip to holder vapour tube and boiling flask |
| R/150/15 | Ball joint clip S-35 |
| R/150/32 | Water bath double walled inner SS with Thermostatic temperature control. |
Rotary Vacuum Evaporator With Thermostatic Control Bath
Reckoned as leaders in this industry, we are providing our esteemed clients with excellent quality Rotary Vacuum Evaporator With Thermostatic Control Bath. The provided evaporator is designed using top notch quality components and modern technology in adherence with quality norms. We assure our clients that this evaporator is tested on variegated parameters in order to ensure its durability. The offered evaporator is used in chemical laboratories for the efficient and gentle removal of solvents from samples by evaporation.
Features
- Jack arrangement fitted
- Glass condenser double coiled
- Flask capacity 800 ml
Specifications
| R/170 | Rotary Vacuum evaporator, Rotavap Series Vertical Condenser, Model PBV-7. This model of evaporator is supplied complete with geared drive unit offering smooth speed control by analog knob, Jack arrangement fitted on base unit for positioning glass assembly, Double walled water bath thermostatically controlled temp., glass condenser double coiled with three opening for vacuum and cooling, pear (kjeldahl) shaped evaporating flask capacity 800 ml., receiver flask capacity one liter fitted with a ball joint, feeding tube and vapour path tube a complete working unit. The same unit can be supplied with round bottom one liter capacity evaporating flask instead of 800ml. per shape. |
| R/170/02 | Vertical condenser double coil with two outlets for water circulation. With S-35 Ball at bottom for connecting to receiving flask. Quick fit type joint at top of condenser. Cock for feed tube on one side while the other side will be connected to motor with ring. |
| R/170/03 | Cone Adapter for condenser to Vacuum pump |
| R/170/06 | Vapour Path Tube B-24, B-29 |
| R/170/07 | Gasket Seal for Vapour Tube (VITON) |
| R/170/11 | Feed Tube for condenser trap |
| R/170/13 | Receiving flask with S-35 cup (socket) joint capacity 1000 ml. |
| R/170/15 | Evaporating Flask kjeldahl cap. 800 ml. B-24 |
| R/170/17 | Evaporating Flask kjeldahl cap. 500 ml. B-24 |
| R/170/19 | Evaporating Flask kjeldahl cap. 300 ml. B-24 |
| R/170/21 | Evaporating Flask kjeldahl cap. 100 ml. B-24 |
| R/170/23 | Tension Spring to hold condenser. |
| R/170/25 | Wire Clip to holder vapour tube and boiling flask |
| R/170/27 | Ball joint clip S-35 |
| R/17032 | Water bath double walled inner SS with Thermostatic temperature control. |
Rotary Vacuum Evaporator With Thermostatic Control Bath
Owing to our in-depth domain expertise, we are providing a qualitative range of Rotary Vacuum Evaporator With Thermostatic Control Bath. The offered evaporator is designed as per industry norms using the finest quality components and cutting edge technology under the guidance of our adroit professionals in sync with set industry norms. Our provided evaporator is supplied complete with geared drive unit offering smooth speed control by analog knob.
Features
- Receiving flask with S-35 cup (socket) joint capacity 1000 ml
- Wire Clip to holder vapour tube and boiling flask
- Unmatched performance
Specifications
| R/175/02 | Cold trap condenser double walled with S-35 Ball at bottom for connecting to receiving flask. Quick fit type joint at top of condenser. Cock for feed tube on one side while the other side will be connected to motor with ring. |
| R/175/06 | Vapour Path Tube B-24, B-29 |
| R/175/07 | Gasket Seal for Vapour Tube (VITON) |
| R/175/11 | Feed Tube for condenser trap |
| R/175/13 | Receiving flask with S-35 cup (socket) joint capacity 1000 ml. |
| R/175/15 | Evaporating Flask kjeldahl cap. 800 ml. B-24 |
| R/175/17 | Evaporating Flask kjeldahl cap. 500 ml. B-24 |
| R/175/19 | Evaporating Flask kjeldahl cap. 300 ml. B-24 |
| R/175/21 | Evaporating Flask kjeldahl cap. 100 ml. B-24 |
| R/175/23 | Tension Spring to hold condenser. |
| R/175/25 | Wire Clip to holder vapour tube and boiling flask |
| R/175/27 | Ball joint clip S-35 |
| R/175/32 | Water bath double walled inner SS with Thermostatic temperature control. |
Rotary Vacuum Evaporator With Digital Bath
To meet diverse requirements of our prestigious clients, we are engaged in providing an excellent range of Rotary Vacuum Evaporator With Digital Bath. The provided evaporator is designed using superior quality components and cutting edge technology in adherence with industry standards. Our quality controllers test this evaporator against variegated parameters in order to ensure its quality. Clients can avail this evaporator from us at budget friendly prices.
Features
- Precision-designed
- Superior performance
- Reliable operation
Specifications
| R/178 | Rotary Vacuum evaporator, Rotavap Series Vertical Condenser, Model PBV-7D. This model of evaporator is supplied complete with geared drive unit offering smooth speed control by analog knob, Jack arrangement fitted on base unit for positioning glass assembly, Double walled water bath having Digital temperature indicator cum controller., glass condenser double coiled with three opening for vacuum and cooling, pear (kjeldahl) shaped evaporating flask capacity 800 ml., receiver flask capacity one liter fitted with a ball joint, feeding tube and vapour path tube a complete working unit. The same unit can be supplied with round bottom one liter capacity evaporating flask instead of 800ml. per shape. |
| R/178/02 | Cold trap condenser double walled with S-35 Ball at bottom for connecting to receiving flask. Quick fit type joint at top of condenser. Cock for feed tube on one side while the other side will be connected to motor with ring. |
| R/178/06 | Vapour Path Tube B-24, B-29 |
| R/178/07 | Gasket Seal for Vapour Tube (VITON) |
| R/178/11 | Feed Tube for condenser trap |
| R/178/13 | Receiving flask with S-35 cup (socket) joint capacity 1000 ml. |
| R/178/15 | Evaporating Flask kjeldahl cap. 800 ml. B-24 |
| R/178/17 | Evaporating Flask kjeldahl cap. 500 ml. B-24 |
| R/178/19 | Evaporating Flask kjeldahl cap. 300 ml. B-24 |
| R/178/21 | Evaporating Flask kjeldahl cap. 100 ml. B-24 |
| R/178/23 | Tension Spring to hold condenser. |
| R/178/25 | Wire Clip to holder vapour tube and boiling flask |
| R/178/27 | Ball joint clip S-35 |
Rotary Vacuum Evaporator With Digital Bath
Specifications
| /171 | Rotary Vacuum evaporator, Rotavap Series Vertical Condenser, Model PBV-7D. This model of evaporator is supplied complete with geared drive unit offering smooth speed control by analog knob, Jack arrangement fitted on base unit for positioning glass assembly, Double walled water bath having Digital temperature indicator cum controller., glass condenser double coiled with three opening for vacuum and cooling, pear (kjeldahl) shaped evaporating flask capacity 800 ml., receiver flask capacity one liter fitted with a ball joint, feeding tube and vapour path tube a complete working unit. The same unit can be supplied with round bottom one liter capacity evaporating flask instead of 800ml. per shape. |
| R/171/02 | Vertical condenser double coil with two outlets for water circulation. With S-35 Ball at bottom for connecting to receiving flask. Quick fit type joint at top of condenser. Cock for feed tube on one side while the other side will be connected to motor with ring. |
| R/171/03 | Cone Adapter for condenser to Vacuum pump |
| R/171/06 | Vapour Path Tube B-24, B-29 |
| R/171/07 | Gasket Seal for Vapour Tube (VITON) |
| R/171/11 | Feed Tube for condenser trap |
| R/171/13 | Receiving flask with S-35 cup (socket) joint capacity 1000 ml. |
| R/171/15 | Evaporating Flask kjeldahl cap. 800 ml. B-24 |
| R/171/17 | Evaporating Flask kjeldahl cap. 500 ml. B-24 |
| R/171/19 | Evaporating Flask kjeldahl cap. 300 ml. B-24 |
| R/171/21 | Evaporating Flask kjeldahl cap. 100 ml. B-24 |
| R/171/23 | Tension Spring to hold condenser. |
| R/171/25 | Wire Clip to holder vapour tube and boiling flask |
| R/171/27 | Ball joint clip S-35 |
| R/150/32 | Water bath double walled inner SS with Thermostatic temperature control. |
